YAMAHA
K-2
cassette deck
Cassette deck
SPEC_LINES14
MANUAL_FILES0
IMAGE_REELS5
ARCHIVE_COMPLETION96%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1978
Audio performance
- Frequency response
- LH Tape : 30 Hz ~ 15kHz/40Hz ~ 13 kHz ± 3 dB CrO2 Tape : 30 Hz ~ 17kHz/40Hz ~ 15 kHz ± 3 dB
- S/N ratio
- 57 dB or More (JIS Standard Level) 52 dB or More (DIN 333 Hz, 3% Distortion)
- THD
- LH Tape : 1.5% or less CrO2 Tape : 2.0% or less
- Input sensitivity
- Mic : 0.3mV/5k ΩLine : 50mV/50k Ω
Chassis and power
- External dimensions
- Width 435x Height 150x Depth 288 mm
- Weight
- 6.9kg
- Power consumption
- 14W
