YAMAHA
K-1/K-1B
cassette deck
Cassette deck
SPEC_LINES15
MANUAL_FILES0
IMAGE_REELS10
ARCHIVE_COMPLETION96%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1978
Audio performance
- Frequency response
- L / H : 30 Hz to 16 kHz ± 3 dB CrO2 : 30 Hz to 18 kHz ± 3 dB
- S/N ratio
- 60 dB or More (JIS Standard Level, CrO2) 52 db or More (DIN, 333 Hz, 3% Strain, CrO2)
- THD
- L and H : 1.0% or less CrO2 : not more than 1.6%
- Input sensitivity
- Mic : 0.3mV/5k ΩLine : 60mV/50k Ω
Chassis and power
- External dimensions
- Width 435x Height 140x Depth 305 mm
- Weight
- 9kg
- Power consumption
- 27 W
- Power supply
- 100 VAC, 50/60Hz
