YAMAHA
K-1x
cassette deck
Cassette deck
SPEC_LINES14
MANUAL_FILES0
IMAGE_REELS2
ARCHIVE_COMPLETION92%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1987
Audio performance
- Frequency response
- 20 Hz to 18 kHz ± 3 dB (normal)20 Hz ~ 20 kHz ± 3 dB (Chrome)20 Hz ~ 23 kHz ± 3 dB (metal)
- S/N ratio
- 56dB(NR off)65dB(Dolby B on)73dB(Dolby C on)95dB(dbx on)
- Input sensitivity
- Line : 40mV/30k Ω
Chassis and power
- External dimensions
- Width 435x Height 134x Depth 380 mm
- Weight
- 7.6kg
- Power consumption
- 25W
