NAKAMICHI
ZX-9
cassette deck
Cassette deck
SPEC_LINES13
MANUAL_FILES0
IMAGE_REELS10
ARCHIVE_COMPLETION96%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1982
- Production years
- 1982-1985
- Country of origin
- Japan
Audio performance
- Frequency response
- 20 Hz ~ 21 kHz ± 3 dB (Recording Level -20dB, ZX Tape)20 Hz to 20 kHz ± 3 dB (recording level -20dB, SX, EXII tape)
- S/N ratio
- Dolby C Type NRon : 72 dB or more (400 Hz, 3% THD, IHF A-WTD, RMS) Dolby B Type NRon : 66 dB or more (400 Hz, 3% THD, IHF A-WTD, RMS)
Chassis and power
- External dimensions
- Width 450x Height 135x Depth 300 mm
- Weight
- Approx. 9.5 kg
- Power consumption
- 45W max.
