Aiwa/Excelia
XK-009
cassette deck
Stereo cassette deck
SPEC_LINES9
MANUAL_FILES0
IMAGE_REELS11
ARCHIVE_COMPLETION96%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1988
Audio performance
- Frequency response
- Normal : 20 Hz to 20 kHz ± 3dB/20Hz to 12 kHz ± 3 dB CrO2 : 20 Hz to 21 kHz ± 3dB/20Hz to 15 kHz ± 3 dB Metal : 20 Hz ~ 22 kHz ± 3dB/20Hz ~ 18 kHz ± 3 dB
- S/N ratio
- 75 dB (Dolby C type on, metal tape) 95 dB (dbx-NRon, metal tape)
Chassis and power
- External dimensions
- Width 469x Height 136x Depth 432.7 mm
- Weight
- 10.2kg
- Power consumption
- 33 W
