COMPONENT_RECORD
Teac/Esoteric/Tascam
V-R1
cassette deck
Cassette deck
SPEC_LINES7
MANUAL_FILES0
IMAGE_REELS6
ARCHIVE_COMPLETION87%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1981
Audio performance
- Frequency response
- 30 Hz ~ 19 kHz (Metal Tape)
- S/N ratio
- 59dB(NR out) 69 dB (Dolby NR in, 5 kHz or higher) 91dB(dbx in)
- Input sensitivity
- Microphone : 0.25mV/-72dB/200 Ω or more compatibleLine : 60mV/50k Ω
Chassis and power
- External dimensions
- Width 436x Height 113x Depth 275 mm
- Weight
- 6.3kg
- Power consumption
- 20W
