COMPONENT_RECORD
Teac/Esoteric/Tascam
234
cassette deck
Cassette deck
SPEC_LINES14
MANUAL_FILES0
IMAGE_REELS3
ARCHIVE_COMPLETION96%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1983
Audio performance
- Frequency response
- 20 Hz ~ 20 kHz + 0 -2dB
- S/N ratio
- Microphone (Instrument input to line output) :68 dB (Trim Max) / 82 dB (Trim Min) (IHF A Hearing Correction)64 dB (Trim Max) / 78 dB (Trim Min) (Inaudible Compensation, 20 Hz to 20 kHz)Line Input to Line Output : 82 dB (IHF A hearing correction)78 dB (inaudible correction, 20 Hz to 20 kHz)
- THD
- 0.05% (1 kHz, Specified Level)
Chassis and power
- External dimensions
- Width 482x Height 147x Depth 357 mm (including angles, legs and projections)Without Rack Angle : Width 440 mm
- Weight
- 9kg
- Power consumption
- 30W
