Teac/Esoteric/Tascam
V-970X
cassette deck
Cassette deck
SPEC_LINES7
MANUAL_FILES0
IMAGE_REELS6
ARCHIVE_COMPLETION87%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1987
Audio performance
- Frequency response
- Metal : 20 Hz ~ 21 kHz (25 Hz ~ 20 kHz ± 3 dB) Chrome : 20 Hz to 20 kHz (25 Hz to 19 kHz ± 3 dB) Normal : 20 Hz to 18 kHz (25 Hz to 17 kHz ± 3 dB)
- S/N ratio
- 60 dB (NR out, 3% THD level, WTD) 70 dB (Dolby B NR in, 5 kHz or higher) 80 dB (Dolby C NR in, 1 kHz or higher) 92 dB (dbx NR in, 1 kHz)
- Input sensitivity
- Line : 60mV/50k Ω or more
Chassis and power
- External dimensions
- Width 471x Height 123.5x Depth 279.5 mm (Including Side Plate)
- Weight
- 6.6 kg (Including Side Plate)
- Power consumption
- 27W
