Sony
TC-TX717
cassette deck
Cassette deck
SPEC_LINES12
MANUAL_FILES0
IMAGE_REELS1
ARCHIVE_COMPLETION82%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1997
Audio performance
- Frequency response
- 30 Hz ~ 15 kHz ± 3 dB (EIAJ, -20dB recording, metal tape)30 Hz ~ 13 kHz ± 3 dB (-4dB recording, metal tape)
- S/N ratio
- 57 dB (EIAJ, Dolby NR off, Metal Tape)73 dB (Dolby NR C, Peak Level, Metal Tape, Acoustic Compensation)
- THD
- 1.8% (3rd harmonic distortion rate, reference recording level of 250nWb/m, 315 Hz sine wave, metal tape)
Chassis and power
- External dimensions
- Width 280x Height 90x Depth 348.5 mm
- Weight
- Approx. 3.2 kg
- Power consumption
- 11W
