Sony
MU-D100
cassette deck
Commercial stereo cassette deck
SPEC_LINES14
MANUAL_FILES0
IMAGE_REELS3
ARCHIVE_COMPLETION96%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1990
Audio performance
- Frequency response
- 20 Hz ~ 17 kHz (TypeII, Chrome Position) 20 Hz to 15 kHz (TypeI, normal position)
- S/N ratio
- DolbyNR off:56dB(EIAJ)DolbyNR C on:69dB(1kHz)
- THD
- 1% (1 kHz, TypeII cassette)
- Input sensitivity
- Pin Jack (Unbalanced) : -10dBs/50k Ω
Chassis and power
- External dimensions
- Width 482x Height 132x Depth 300 mm
- Weight
- 7.5kg
- Power consumption
- 22W
