COMPONENT_RECORD
Sony
TC-RX711
cassette deck
Cassette deck
SPEC_LINES12
MANUAL_FILES0
IMAGE_REELS1
ARCHIVE_COMPLETION82%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1993
Audio performance
- Frequency response
- 25 Hz to 19 kHz ± 3 dB (EIAJ, -20dB recording, metal tape)30 Hz ~ 15 kHz ± 3 dB (-4dB recording, metal tape)
- S/N ratio
- 57 dB (EIAJ, Dolby off, peak level, metal tape)74 dB (Dolby NRC, peak level, metal tape)
- THD
- 1.8% (3rd harmonic distortion rate, reference recording level of 250nWb/m, 315 Hz sine wave, metal tape)
Chassis and power
- External dimensions
- Width 430x Height 125x Depth 295 mm
- Weight
- 4.8kg
- Power consumption
- 16W
