Sony
TC-KA3ES
cassette deck
Cassette deck
SPEC_LINES13
MANUAL_FILES0
IMAGE_REELS4
ARCHIVE_COMPLETION96%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1995
Audio performance
- Frequency response
- 15 Hz ~ 22 kHz ± 3 db (EIAJ, -20dB recording, metal tape)15 Hz ~ 16 kHz ± 3 db (-4dB recording, metal tape)
- S/N ratio
- 57 dB (EIAJ, Dolby NR off, Metal Tape)80 dB (Dolby NRS, Peak Level, Metal Tape, Acoustic Compensation)
- THD
- 1.3% (3rd harmonic distortion rate, reference recording level of 250nWb/m, 315 Hz sine wave, metal tape)
Chassis and power
- External dimensions
- Width 430x Height 135x Depth 360 mm
- Weight
- Approx. 7.6 kg
- Power consumption
- 23W
