COMPONENT_RECORD
Sony
TC-K7II/TC-K7BII
cassette deck
Stereo cassette deck
SPEC_LINES11
MANUAL_FILES1
IMAGE_REELS2
ARCHIVE_COMPLETION89%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1977
Audio performance
- Frequency response
- 20 Hz ~ 18kHz/30Hz ~ 16 kHz ± 3 dB (Fe-Cr) 20 Hz ~ 17.7kHz/30Hz ~ 15 kHz ± 3 dB (CrO2) 20 Hz to 15 kHz (Normal)
- S/N ratio
- 60 dB (Fe-Cr, peak level, Dolby NR off) 56 dB (CrO2, peak level, Dolby NR off) Dolby NRon : 5 dB improvement (at 1 kHz), 10 dB improvement (5 kHz or more)
Chassis and power
- External dimensions
- Width 430x Height 170x Depth 310 mm
- Weight
- 10kg
- Power consumption
- 26W
