Sony
TC-2250SD
cassette deck
Dolby built-in cassette deck
SPEC_LINES13
MANUAL_FILES0
IMAGE_REELS3
ARCHIVE_COMPLETION93%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1972
Audio performance
- Frequency response
- 20 Hz ~ 17 kHz (when Sony Chromicassette is used)20 Hz ~ 15 kHz (When Using General Tape)
- S/N ratio
- 49 dB (Dolby In : 1 kHz 5 dB, 5 kHz 10 dB improvement)
- Input sensitivity
- My Kujac (2 systems) : maximum sensitivity 0.2 mV / low impedanceLine input jack (2 systems) : maximum sensitivity 0.06V/100k ΩRe-connector (input side) : 2.2k Ω
Chassis and power
- External dimensions
- Width 400x Height 127x Depth 276 mm
- Weight
- 6.6kg
- Power consumption
- 18W
