Victor/JVC
KD-V6
cassette deck
Stereo cassette deck
SPEC_LINES14
MANUAL_FILES0
IMAGE_REELS3
ARCHIVE_COMPLETION96%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1983
Audio performance
- Frequency response
- Metal : 20 Hz ~ 19 kHz ± 3 dB Chrome : 20 Hz ~ 19 kHz ± 3 dB Normal : 20 Hz to 18 kHz ± 3 dB
- S/N ratio
- NR off : 54 dB (metal, EIAJ)58 dB (WTD, 1 kHz, 3% 3rd harmonic distortion factor, metal)Dolby B on : 5 dB improvement at 1 kHz, 10 dB improvement at 5 kHz or higherDolby C on : Approx. 15 db at 500 hz, up to 20 db at 1 khz to 10 khzMOL improvement effect : 4 db improvement at 10 khz
- THD
- 0.5% (1 kHz, 3rd harmonic distortion factor, metal tape, EIAJ)
Chassis and power
- External dimensions
- Width 435x Height 110x Depth 282 mm
- Weight
- Approx. 4.5 kg
- Power consumption
- 18W
