COMPONENT_RECORD
Victor/JVC
DD-10
cassette deck
Stereo cassette deck
SPEC_LINES14
MANUAL_FILES0
IMAGE_REELS4
ARCHIVE_COMPLETION96%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1981
Audio performance
- Frequency response
- Metal : 25 Hz to 18 kHz ± 3 dB (-20VU recording)25 Hz to 12.5 kHz ± 3 dB (0 VU recording)
- S/N ratio
- NR off : 55 dB (metal)60 dB (WTD, 1 kHz, 3% 3rd harmonic distortion factor, metal)Dolby B on : 5 dB improvement at 1 kHz, 10 dB improvement at 5 kHz or higherDolby C on : Approx. 15 dB at 500 Hz, approx. 20 dB at 1 kHz to 10 kHzMOL improvement effect : 4 db improvement at 10 khz
Chassis and power
- External dimensions
- Width 450x Height 110x Depth 325 mm
- Weight
- Approx. 8.4 kg
- Power consumption
- 40 W
- Power supply
- 100 VAC, 50Hz/60Hz
