COMPONENT_RECORD
Victor/JVC
KD-85SA
cassette deck
Stereo cassette deck
SPEC_LINES15
MANUAL_FILES0
IMAGE_REELS6
ARCHIVE_COMPLETION96%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1977
Audio performance
- Frequency response
- 0 VU recording : 6 dB at 10 kHz+ 5 VU recording : 12 dB at 10 kHz
- S/N ratio
- ANRS off : 60 dB (WTD, 1 kHz, 3% THD, VX tape) ANRS on : 5 dB improvement at 1 kHz, 10 dB improvement at 5 kHz or higher * Effect of Super ANRS Signal-to-noise ratio : Same as the ANRS effect
- THD
- 0 VU recording : 3% or less at 10 kHz+ 5 VU recording : <3% at 10 kHz
- Input sensitivity
- Mic : Maximum sensitivity 0.2 mV (-72dBs) / 600 ~ 10k ΩLine in : Minimum input level 80 mv (-20dBs) / 100k ΩDin : minimum input level 9 mV (-39dBs) / 10k Ω
Chassis and power
- External dimensions
- Width 450x Height 158x Depth 327 mmWidth 480x Height 158x Depth 337 mm (Handle Mounted)
- Weight
- 9.9kg
- Power consumption
- 30W
