COMPONENT_RECORD
Victor/JVC
KD-4
cassette deck
Namaro Component Cassette Deck
SPEC_LINES13
MANUAL_FILES0
IMAGE_REELS6
ARCHIVE_COMPLETION96%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1976
Audio performance
- Frequency response
- Chrome : 25 Hz to 18 kHz (45 Hz to 16 kHz ± 3 dB)SF : 25 Hz to 17 kHz (45 Hz to 15 kHz ± 3 dB)
- S/N ratio
- ANRS off:57dB(JIS)54 dB at peak levelANRS on : 5 dB improvement at 1 kHz, 10 dB improvement at 5 kHz or higher
- THD
- 1.2% (SF tape, 1 kHz, 0 VU recording)
Chassis and power
- External dimensions
- Width 370x Height 100x Depth 245 mm
- Weight
- 4.6 kg (excluding battery)5.2 kg (including battery)
- Power consumption
- 10W (at 100 VAC, 50Hz/60Hz)5W at 9 v DC, SUM-1x6
