COMPONENT_RECORD
Sansui
D-570
cassette deck
Stereo cassette deck
SPEC_LINES7
MANUAL_FILES0
IMAGE_REELS3
ARCHIVE_COMPLETION75%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1982
Audio performance
- Frequency response
- Metal Tape : 20 Hz ~ 22 kHz (30 Hz ~ 21 kHz ± 3 dB) CrO220 Hz to 19 kHz (30 Hz to 18 kHz ± 3 dB) LH : 20 Hz ~ 17 kHz (30 Hz ~ 16 kHz ± 3 dB)
- S/N ratio
- Dolby off : 60 dB or more Dolby B : 10 dB improvement at 5 kHz or more Dolby C : 20 dB improvement at 1 kHz or higher
- Input sensitivity
- Mic : 0.4mV/200 Ω ~ 5k Ω Line : 70mV/47k Ω
Chassis and power
- External dimensions
- Width 430x Height 111x Depth 324 mm
- Weight
- 6.5kg
- Power consumption
- 25W
