COMPONENT_RECORD
PIONEER/EXCLUSIVE/TAD
CT-A1
cassette deck
Compact Cassette Tape Deck
SPEC_LINES11
MANUAL_FILES0
IMAGE_REELS8
ARCHIVE_COMPLETION96%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1980
Audio performance
- Frequency response
- STD, LH Tape : 20 Hz to 19 kHz, 25 Hz to 16 kHz ± 3 dB (at -20dB recording)
- S/N ratio
- Dolby off : 60 dB or more Dolby on : 70 dB or more (5 kHz or more)
- THD
- 1.0% or less (0 dB)
- Input sensitivity
- Line : 65mV/15V/100k Ω, Pin Jack Microphone : 0.3mV/100mV/10k Ω, 6 mm Diameter Jack (Applicable Microphone Impedance : 250 Ω ~ 10k Ω)
Chassis and power
- External dimensions
- Width 420x Height 217x Depth 390 mm
- Weight
- 18kg
- Power consumption
- 45W
