COMPONENT_RECORD
PIONEER/EXCLUSIVE/TAD
CT-1000
cassette deck
Cassette deck
SPEC_LINES10
MANUAL_FILES0
IMAGE_REELS3
ARCHIVE_COMPLETION84%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1979
Audio performance
- Frequency response
- General, LH Tape : 20 Hz ~ 17kHz/30Hz ~ 15 kHz ± 3 dBFerrichrome Tape : 20 Hz ~ 19kHz/30Hz ~ 17 kHz ± 3 dBChrome Tape : 20 Hz ~ 19kHz/30Hz ~ 17 kHz ± 3 dB
- S/N ratio
- Dolby OFF : 54 dB or more (General / LH Tape)Dolby ON : 64 dB or More (5 kHz or More, General / LH Tape)* When chrome tape is used, it is further improved by 4.5 db (5 khz or more).
- THD
- 1.3% or less (0 dB)
Chassis and power
- External dimensions
- Width 420x Height 187x Depth 362 mmWidth 480x Height 187x Depth 362 mm (when JA-R102 is attached)
- Weight
- 11.7kg
- Power consumption
- 38W
