PIONEER/EXCLUSIVE/TAD
CT-9/CT-97
cassette deck
Stereo cassette deck
SPEC_LINES11
MANUAL_FILES0
IMAGE_REELS3
ARCHIVE_COMPLETION87%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1975
Audio performance
- Frequency response
- General, LH Tape : 25 Hz ~ 16 kHz, 35 Hz ~ 13 kHz ± 3 dBChrome Tape : 20 Hz ~ 17 kHz, 30 Hz ~ 14 kHz ± 3 dB
- S/N ratio
- Generic, LH tape Dolby off : 52 dB or more Dolby on : 62 dB or more (5 kHz or more)
- THD
- 1.7% or less (0 dB)
- Input sensitivity
- Microphone : 0.22mV/100MV/30k Ω (Compatible Microphone Impedance 600 Ω ~ 30k Ω) Line : 65mV/100k Ω DINx1 (West German DIN standard)
Chassis and power
- External dimensions
- Width 420x Height 197x Depth 310 mm
- Weight
- 12kg
- Power consumption
- 50W maximum
