PIONEER/EXCLUSIVE/TAD
CT-7A
cassette deck
Compact cassette deck
SPEC_LINES11
MANUAL_FILES0
IMAGE_REELS2
ARCHIVE_COMPLETION83%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1975
Audio performance
- Frequency response
- General, LH Tape : 30 Hz ~ 13000 Hz (40 Hz ~ 12000 Hz ± 3 dB)Chrome Tape : 30 Hz ~ 16500 Hz (40 Hz ~ 13500 Hz ± 3 dB)
- S/N ratio
- Dolby OFF : 50 dB (General, LH Tape)Dolby ON : 60 dB (General, LH Tape, 5 kHz or more)4.5 db higher when chrome tape is used (5 khz or more)
- THD
- Not more than 1.7%
- Input sensitivity
- Microphone (2 systems) : 0.2mV/90mV/90k Ω (Compatible Microphone : 600 Ω ~ 50k Ω, 6 φ Jack) Line (2 Systems) : 60mV/25V/180k Ω (Pin Jack) Recording / Playback : 10mV/4.5V/1.8k Ω (West German DIN, 5P jack)
Chassis and power
- External dimensions
- Width 420x Height 151x Depth 337 mm
- Weight
- 9.4kg
- Power consumption
- 18W
