COMPONENT_RECORD
NAKAMICHI
CassetteDeck1
cassette deck
Stereo cassette deck
SPEC_LINES7
MANUAL_FILES0
IMAGE_REELS3
ARCHIVE_COMPLETION75%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1990
- Production years
- 1990-1992
Audio performance
- Frequency response
- 20 Hz to 21 kHz ± 3 dB (recording level -20dB, TypeI/II/IV, EIAJ)
- S/N ratio
- DolbyNR B on : 66 dB or more (400 Hz, 3% THD, IHF A-WTD RMS) DolbyNR C on : 72 dB or more (400 Hz, 3% THD, IHF A-WTD RMS)
- Input sensitivity
- Line : 50mV/40k Ω
Chassis and power
- External dimensions
- Width 430x Height 100x Depth 320 mm (EIAJ)
- Weight
- Approx. 5.4 kg
- Power consumption
- 25W max.
