Teac/Esoteric/Tascam
C-1mkII
cassette deck
Cassette deck
SPEC_LINES12
MANUAL_FILES0
IMAGE_REELS2
ARCHIVE_COMPLETION86%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1979
Audio performance
- Frequency response
- Metal Tape : 20 Hz ~ 22 kHz (30 Hz ~ 20 kHz ± 3 dB)Cobalt Tape : 20 Hz to 20 kHz (30 Hz to 18 kHz ± 3 dB)Hi-Fi Tape : 20 Hz ~ 17 kHz (30 Hz ~ 16 kHz ± 3 dB)
- S/N ratio
- 60 dB (3% distortion level, audibility correction) Dolby System Recovery : 5 dB (1 kHz), 10 dB (5 kHz or more) dbx in:80dB
Chassis and power
- External dimensions
- Width 482x Height 161x Depth 353 mm
- Weight
- 14.5kg
- Power consumption
- 28W
