COMPONENT_RECORD
Aiwa/Excelia
AD-FF8
cassette deck
Stereo cassette deck
SPEC_LINES11
MANUAL_FILES0
IMAGE_REELS2
ARCHIVE_COMPLETION83%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1981
Audio performance
- Frequency response
- LH : 20 Hz to 17 kHz CrO2 : 20 Hz to 19kHz/25Hz to 8 kHz + 2-3 dB FeCr : 20 Hz ~ 20kHz/25Hz ~ 12.5 kHz + 2 -3dB Metal : 20 Hz ~ 20kHz/25Hz ~ 12.5 kHz + 2 -3dB
- S/N ratio
- 60dB(Dolby NR off)68 dB (Dolby Btype on, metal tape, peak level)75 dB (Dolby Ctype on, metal tape, peak level)
- THD
- FeCr:0.8%Metal:0.9%
- Input sensitivity
- Line : 50mV/50k Ω or moreMic : 0.3mV/200 Ω ~ 10k Ω
Chassis and power
- External dimensions
- Width 420x Height 110x Depth 265 mm
- Weight
- 5.1kg
- Power consumption
- 26W
