Aiwa/Excelia

AD-F600

cassette deck

Stereo cassette deck

SPEC_LINES11
MANUAL_FILES0
IMAGE_REELS2
ARCHIVE_COMPLETION83%
Specifications

TECHNICAL_DATA

Specifications

Overview

Deck type
cassette_deck
Release year
1980

Audio performance

Frequency response
LH Tape : 20 Hz to 17 kHz CrO2 : 20 Hz to 19kHz/30Hz to 8 kHz + 2-3 dB Metal : 20 Hz ~ 20kHz/30Hz ~ 12.5 kHz + 2 -3dB
S/N ratio
68 dB (Dolby NRon, Metal tape) 53 dB (Dolby NR off, LH tape)
THD
0.8% (Metal Tape)
Input sensitivity
Line : 50mV/50k Ω or moreMic : 0.3mV/200 Ω ~ 10k Ω

Chassis and power

External dimensions
Width 420x Height 109x Depth 285 mm
Weight
5.3kg
Power consumption
18W
