COMPONENT_RECORD
Aiwa/Excelia
AD-7400
cassette deck
Stereo cassette deck
SPEC_LINES11
MANUAL_FILES0
IMAGE_REELS6
ARCHIVE_COMPLETION96%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1977
Audio performance
- Frequency response
- LH Tape : 20 Hz ~ 15 kHz (30 Hz ~ 13 kHz ± 3 dB)FeCr Tape : 20 Hz ~ 17 kHz (30 Hz ~ 15 kHz ± 3 dB)CrO2Tape : 20 Hz to 17 kHz (30 Hz to 15 kHz ± 3 dB)
- S/N ratio
- 65 dB (Dolby NRon, FeCr, peak level)
- Input sensitivity
- Line : 50mV/50k Ω or moreDin : 0.1mV/3k ΩMic : 0.3mV/200 ~ 10k Ω Compatible
Chassis and power
- External dimensions
- Width 420x Height 150x Depth 300 mm
- Weight
- 7.5kg
- Power consumption
- 10W
