COMPONENT_RECORD
Teac/Esoteric/Tascam
A-360
cassette deck
Stereo cassette deck
SPEC_LINES12
MANUAL_FILES0
IMAGE_REELS6
ARCHIVE_COMPLETION96%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1974
Audio performance
- Frequency response
- 30 Hz ~ 16 kHz (Chrome Tape)30 Hz ~ 13 kHz (Hi-Fi Tape)30 Hz ~ 10 kHz (Regular Tape)
- S/N ratio
- NR out : 50 dB (3% distortion level, audibility correction)Dolby Improvement : 5 dB (1 kHz), 10 dB (5 kHz or more)
- Input sensitivity
- Line : 0.1V/50k Ω or moreMicrophone : 0.25mV/-72dB/600 Ω ~ 10k Ω Compatible
Chassis and power
- External dimensions
- Width 450x Height 120x Depth 260 mm
- Weight
- 7.5kg
- Power consumption
- 14W
