COMPONENT_RECORD
NAKAMICHI
681ZX
cassette deck
Stereo cassette deck
SPEC_LINES8
MANUAL_FILES0
IMAGE_REELS7
ARCHIVE_COMPLETION94%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1981
- Production years
- 1980-1982
Audio performance
- Frequency response
- 20 Hz ~ 22 kHz ± 3 dB (ZX Tape) 20 Hz ~ 20 kHz ± 3 dB (SX, EXII tape)
- S/N ratio
- Dolby C on : 72 dB or more (70 μ s, ZX Tape) Dolby B on : 66 dB or more (70 μ s, ZX Tape)
- THD
- 0.8% or Less (ZX Tape) 1.0% or Less (SX, EXII tape)
- Input sensitivity
- 50mV/50k Ω
Chassis and power
- External dimensions
- Width 482x Height 143x Depth 340 mm
- Weight
- Approximately 9 kg
- Power consumption
- 36W max.
