COMPONENT_RECORD
NAKAMICHI
680ZX
cassette deck
Cassette deck
SPEC_LINES14
MANUAL_FILES0
IMAGE_REELS7
ARCHIVE_COMPLETION96%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1980
- Production years
- 1979-1980
- Country of origin
- Japan
Audio performance
- Frequency response
- 4.8cm/s: 2.4cm/s: 10 Hz to 22 kHz ± 3 dB 10 Hz ~ 15 kHz ± 3 dB (Equalizer 120 μ s, ZX Tape)
- S/N ratio
- 4.8cm/s: 2.4cm/s: 60 dB or greater (0 dB, WTD rms) 66 dB or more (3% THD, WTDrms, Dolby NRin, 70 μ s) 60 dB or more (3% THD, WTDrms, Dolby NRin, 120 μ s)
- THD
- 4.8cm/s: 2.4cm/s: 0.8% or Less (ZX Tape) 1.0% or less (SX/EXII tape) 1.5% or Less (ZX Tape)
Chassis and power
- External dimensions
- Width 482x Height 143x Depth 340 mm
- Weight
- Approximately 9 kg
- Power consumption
- 30W max.
