NAKAMICHI
660ZX
cassette deck
Cassette deck
SPEC_LINES7
MANUAL_FILES0
IMAGE_REELS7
ARCHIVE_COMPLETION91%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1980
- Production years
- 1979-1981
Audio performance
- Frequency response
- 10 Hz ~ 22 kHz ± 3 dB (ZX Tape)10 Hz ~ 20 kHz ± 3 db (SX, EXII tape)
- S/N ratio
- 60 dB or greater (0 dB, WTD rms) 66 dB or more (3% THD, WTDrms, Dolby NRin, 70 μ s)
- THD
- 0.8% or Less (ZX Tape) 1.0% or less (SX/EXII tape)
Chassis and power
- External dimensions
- Width 482x Height 143x Depth 340 mm
- Weight
- Approximately 9 kg
- Power consumption
- 27W max.
