COMPONENT_RECORD
NAKAMICHI
581Z
cassette deck
Cassette deck
SPEC_LINES14
MANUAL_FILES0
IMAGE_REELS5
ARCHIVE_COMPLETION96%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1981
- Production years
- 1981-1982
Audio performance
- Frequency response
- 20 Hz to 20 kHz
- S/N ratio
- Dolby B NR in : 66 dB or more (400 Hz, 3% THD, IHF-A wtd rms) Dolby C NR in : 72 dB or more (400 Hz, 3% THD, IHF-A wtd rms)
- THD
- 0.8% or Less (ZX Tape) 1.0% or Less (SX, EX II tape)
Chassis and power
- External dimensions
- Width 500x Height 130x Depth 350 mm
- Weight
- Approx. 8.3 kg
- Power consumption
- 30W max.
