COMPONENT_RECORD
MARANTZ
SD-74
cassette deck
Cassette deck
SPEC_LINES7
MANUAL_FILES0
IMAGE_REELS8
ARCHIVE_COMPLETION95%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1985
Audio performance
- Frequency response
- 20 Hz to 20 kHz (metal)20 Hz ~ 19 kHz (Chrome)20 Hz ~ 18 kHz (Normal)
- S/N ratio
- 54 dB (EIAJ, peak recording level hearing correction)Dolby B on : 10 dB improvement (over 5 kHz)Dolby C on : 20 dB improvement (1 kHz to 10 kHz)Dbx on : 30 db improvement (1 khz)
- Input sensitivity
- Line : 70mV/50k Ω
Chassis and power
- External dimensions
- Width 416x Height 118x Depth 334 mm
- Weight
- 6.5kg
- Power consumption
- 30W
