SHARP/OPTONICA
RT-9
cassette deck
Stereo cassette deck
SPEC_LINES8
MANUAL_FILES0
IMAGE_REELS5
ARCHIVE_COMPLETION86%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1979
Audio performance
- Frequency response
- 20 Hz to 22 kHz (metal)20 Hz ~ 20 kHz (Fe-Cr)20 Hz ~ 20 kHz (Chrome)20 Hz ~ 18 kHz (Normal)
- S/N ratio
- Dolby off:60dB(Fe-Cr)Dolby on : 70 dB (Fe-Cr, 5 kHz or more)
- THD
- 1.0%
- Input sensitivity
- Microphone : 0.28mV/6.8k Ω Aux, Line : 70mV/50k Ω
Chassis and power
- External dimensions
- Width 430x Height 144x Depth 371 mm
- Weight
- 12.5kg
- Power consumption
- 43W
