Technics / Panasonic
RS-M273
cassette deck
Stereo cassette deck
SPEC_LINES13
MANUAL_FILES0
IMAGE_REELS2
ARCHIVE_COMPLETION89%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1981
Audio performance
- Frequency response
- Normal (XD) : 20 Hz to 19 kHzNormal : 30 Hz to 17 kHz ± 3 dB (EIAJ)CrO2 (XAII) : 20 Hz to 20 kHz, 30 Hz to 18 kHz ± 3 dB (EIAJ)Metal (MX) : 20 Hz ~ 21 kHz, 30 Hz ~ 19 kHz ± 3 dB (EIAJ)
- S/N ratio
- NR off : 58 dB (XAII Tape, WTD, 1 kHz, 3% THD)55 dB (XAII tape, EIAJ)Dolby NR in : 10 db improvement (5 khz or higher)
Chassis and power
- External dimensions
- Width 430x Height 109x Depth 340 mm (Including Knob and Rubber Leg)
- Weight
- Approx. 6.3 kg
- Power consumption
- AC18W
