COMPONENT_RECORD
Technics / Panasonic
RS-B905
three head cassette deck
3-head cassette deck
SPEC_LINES12
MANUAL_FILES0
IMAGE_REELS3
ARCHIVE_COMPLETION90%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- three_head_cassette_deck
- Release year
- 1987
Audio performance
- Frequency response
- Normal (ED) : 20 Hz to 20 kHz, 30 Hz to 18 kHz ± 3 dB (EIAJ)CrO2(EX) : 20 Hz to 21 kHz, 30 Hz to 19 kHz ± 3 dB (EIAJ)Metal (EM) : 20 Hz to 22 kHz, 30 Hz to 20 kHz ± 3 dB (EIAJ)
- S/N ratio
- NR off : 60 dB (Chrome Tape, W. T. D., 1 kHz, 3% Third Order Distortion)56 dB (Chrome Tape, EIAJ)Dolby B NR in : 66 dB (EX Tape, W. T. D., 1 kHz, 3% third order distortion)Dolby C NR in : 72 dB (EX Tape, W. T. D., 1 kHz, 3% third order distortion)Dbx in : 92 dB (Chrome Tape, W. T. D., 1 kHz, 3% Third Order Distortion)
Chassis and power
- External dimensions
- Width 430x Height 109.5x Depth 285 mm
- Weight
- 5kg
- Power consumption
- 25W
