Technics / Panasonic
RS-B66W
double cassette deck
Stereo double cassette deck
SPEC_LINES11
MANUAL_FILES0
IMAGE_REELS2
ARCHIVE_COMPLETION83%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- double_cassette_deck
- Release year
- 1986
Audio performance
- Frequency response
- Normal (ED) : 20 Hz to 19 kHz, 30 Hz to 17 kHz ± 3 dB (EIAJ)CrO2(EX) : 20 Hz to 20 kHz, 30 Hz to 18 kHz ± 3 dB (EIAJ)Metal (EM) : 20 Hz to 21 kHz, 30 Hz to 19 kHz ± 3 dB (EIAJ)
- S/N ratio
- NR off : 57 dB (EX tape, WTD, 1 kHz, 3% third order distortion)55 dB (EX tape, EIAJ)Dolby B NR in : 66 dB (EX Tape, WTD, 1 kHz, 3% third order distortion)Dolby C NR in : 72 dB (EX Tape, WTD, 1 kHz, 3% third order distortion)Dbx in : 92 dB (EX tape, WTD, 1 kHz, 3% third order distortion)
Chassis and power
- External dimensions
- Width 430x Height 110x Depth 325 mm
- Weight
- 6.7kg
- Power consumption
- 20W
