COMPONENT_RECORD
Technics / Panasonic
RS-AZ7
cassette deck
Cassette deck
SPEC_LINES13
MANUAL_FILES0
IMAGE_REELS4
ARCHIVE_COMPLETION96%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1996
Audio performance
- Frequency response
- Normal : 20 Hz to 17 kHz ± 3 dBHigh Positive : 20 Hz ~ 18 kHz ± 3 dBMetal : 20 Hz ~ 23 kHz ± 3 dB
- S/N ratio
- NRoff : 62 dB (WTD, 315 Hz, 3% third order distortion factor) 58dB(EIAJ) Dolby B NRon : 71 dB (WTD, 315 Hz, 3% third order distortion factor) Dolby C NRon : 78 dB (WTD, 315 Hz, 3% third order distortion factor)
- Input sensitivity
- 100mV/47k Ω
Chassis and power
- External dimensions
- Width 430x Height 125x Depth 290 mm
- Weight
- 4.2kg
- Power consumption
- 19W
