COMPONENT_RECORD
Technics / Panasonic
RS-676U
cassette deck
Cassette stereo tape deck
SPEC_LINES13
MANUAL_FILES0
IMAGE_REELS3
ARCHIVE_COMPLETION93%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1973
Audio performance
- Frequency response
- Normal : 20 Hz to 14 kHzCrO2: 20 Hz to 15 kHz
- S/N ratio
- Dolby out : 50 dB or moreDolby in : 58 dB or more
- Input sensitivity
- Mic : 0.3 mV (-70dB) / 600 Ω ~ 20k Ω Line in : 60 mv (-24dB) / 110k Ω Tuner : 100 mV (-20dB) / 190k Ω
Chassis and power
- External dimensions
- Width 410x Height 140x Depth 360 mm
- Weight
- Approx. 10.5 kg
- Power consumption
- Approx. 25W
