COMPONENT_RECORD
Trio/Kenwood
KX-5000
cassette deck
Stereo cassette deck
SPEC_LINES13
MANUAL_FILES0
IMAGE_REELS3
ARCHIVE_COMPLETION93%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1975
Audio performance
- Frequency response
- Normal : 30 Hz to 13 kHz + 1 -3dBChrome : 30 Hz ~ 15 kHz + 1-3 dB
- S/N ratio
- Dolby off : 50 dB (normal)53 dB (Chrome)Dolby on : 58 dB (normal)61 dB (Chrome)
- Input sensitivity
- Mic : 0.2 mV (-72dB) / 8k Ω DIN : 0.4mV/4k Ω Line : 77.5mV/180k Ω ATT(Mic/DIN):-12dB
Chassis and power
- External dimensions
- Width 430x Height 149x Depth 300 mm
- Weight
- 7kg
- Power consumption
- 8.5W
