AKAI/A&D

GXC-704D

cassette deck

Cassette deck

SPEC_LINES8
MANUAL_FILES0
IMAGE_REELS4
ARCHIVE_COMPLETION82%
Specifications

TECHNICAL_DATA

Specifications

Overview

Deck type
cassette_deck
Release year
1979

Audio performance

Frequency response
35 Hz ~ 14 kHz ± 3 dB (LN Tape)35 Hz ~ 14 kHz ± 3 dB (LH Tape)35 Hz ~ 15 kHz ± 3 dB (CrO2 (SA) Tape)35 Hz ~ 15 kHz ± 3 dB (FeCr Tape)
S/N ratio
54 dB (LN/LH Tape) 56 dB (CrO2 (SA) / FeCr Tape) Improvement amount when using Dolby NR : 6 db (1 khz), 10 db (5 khz)
THD
1.3% (LN/LH Tape)
Input sensitivity
Mic : 0.25mV/600 Ω CompatibleLine : 70mV/100k Ω

Chassis and power

External dimensions
Width 380x Height 150x Depth 295 mm
Weight
6.1kg
Power consumption
10W
