COMPONENT_RECORD
AKAI/A&D
GX-Z7000
cassette deck
Cassette deck
SPEC_LINES8
MANUAL_FILES0
IMAGE_REELS6
ARCHIVE_COMPLETION90%
TECHNICAL_DATA
Specifications
Overview
- Deck type
- cassette_deck
- Release year
- 1987
Audio performance
- Frequency response
- 20 Hz ~ 19 kHz ± 3 dB (Normal Tape)20 Hz ~ 20 kHz ± 3 dB (Chrome Tape)20 Hz ~ 21 kHz ± 3 dB (Metal Tape)
- S/N ratio
- 59 dB (Metal Tape) Dolby B NR : 5 dB improvement at 1 kHz, 10 dB improvement at 5 kHz or higher Dolby C NR : 15 dB improvement at 500 Hz, 20 dB improvement at 1 kHz to 10 kHz
- THD
- 0.5% (Metal Tape)
- Input sensitivity
- Line : 70mV/47k Ω
Chassis and power
- External dimensions
- Width 440x Height 111x Depth 353 mm
- Weight
- 6.5kg
- Power consumption
- 19W
